| Cummins 4BTA3.9-C80 Construction Engine Specifications | |
| Engine Model | 4BTA3.9-C80 |
| Rated Power | 60kW/80HP |
| Rated Speed | 2200 RPM |
| Engine Type | 4 Cylinders, in Line |
| Bore*Stroke(mm) | 102 mm * 120 mm |
| Displacement | 3.9 L |
| Compression Ratio | 18:01 |
| Peak Torque | 330N.m @1500r/min |
| Fuel Consumption | 18.6 L/hr |
| Aspiration Type | Turbocharged |
| Cooling Method | Water Cooled |
| Start Type | 24V, Electric Start |
| Fuel System | Wuxi Weifu A Pump/ RSV Govenor |
| Packing Weight | 500KG |
| Dimension | 1000mm*870mm*1200mm |
| Cummins diesel engine 4BTA3.9-C80 trade information | |
| Warranty Time | 1 year or 1000 hours, which one comes first |
| Delivery Port | Shanghai or any China port |
| Leading Time | 15 working days |
| Trade Termes | FOB/CIF |
| Payement termes | T/T, L/C |
| Cummins 4BTA3.9-C100 Construction Engine Specifications | |
| Engine Model | 4BTA3.9-C100 |
| Rated Power | 74kW/100HP |
| Rated Speed | 2200RPM |
| Engine Type | 4 Cylinders, in Line |
| Bore*Stroke(mm) | 102 mm * 120 mm |
| Displacement | 3.9 L |
| Compression Ratio | 18:01 |
| Peak Torque | 330N.m @1500r/min |
| Fuel Consumption | 18.6 L/hr |
| Aspiration Type | Turbocharged |
| Cooling Method | Water Cooled |
| Start Type | 24V, Electric Start |
| Fuel System | Wuxi Weifu A Pump/ RSV Govenor |
| Packing Weight | 500KG |
| Dimension | 1000mm*870mm*1200mm |
| Cummins 4BTA3.9-C110 Construction Engine Specifications | |
| Engine Model | 4BTA3.9-C110 |
| Rated Power | 82kW/110HP |
| Rated Speed | 2200RPM |
| Engine Type | 4 Cylinders, in Line |
| Bore*Stroke(mm) | 102 mm * 120 mm |
| Displacement | 3.9 L |
| Compression Ratio | 18:01 |
| Peak Torque | 330N.m @1500r/min |
| Fuel Consumption | 18.6 L/hr |
| Aspiration Type | Turbocharged |
| Cooling Method | Water Cooled |
| Start Type | 24V, Electric Start |
| Fuel System | Wuxi Weifu A Pump/ RSV Govenor |
| Packing Weight | 500KG |
| Dimension | 1000mm*870mm*1200mm |
| Cummins 4BTA3.9-C120 Construction Engine Specifications | |
| Engine Model | 4BTA3.9-C120 |
| Rated Power | 90kW/120HP |
| Rated Speed | 2400RPM |
| Engine Type | 4 Cylinders, in Line |
| Bore*Stroke(mm) | 102 mm * 120 mm |
| Displacement | 3.9 L |
| Compression Ratio | 18:01 |
| Peak Torque | 330N.m @1500r/min |
| Fuel Consumption | 18.6 L/hr |
| Aspiration Type | Turbocharged |
| Cooling Method | Water Cooled |
| Start Type | 24V, Electric Start |
| Fuel System | Wuxi Weifu A Pump/ RSV Govenor |
| Packing Weight | 500KG |
| Dimension | 1000mm*870mm*1200mm |
| Cummins 4BTA3.9-C125 Construction Engine Specifications | |
| Engine Model | 4BTA3.9-C125 |
| Rated Power | 93kW/125HP |
| Rated Speed | 2200RPM |
| Engine Type | 4 Cylinders, in Line |
| Bore*Stroke(mm) | 102 mm * 120 mm |
| Displacement | 3.9 L |
| Compression Ratio | 18:01 |
| Peak Torque | 330N.m @1500r/min |
| Fuel Consumption | 18.6 L/hr |
| Aspiration Type | Turbocharged |
| Cooling Method | Water Cooled |
| Start Type | 24V, Electric Start |
| Fuel System | Wuxi Weifu A Pump/ RSV Govenor |
| Packing Weight | 500KG |
| Dimension | 1000mm*870mm*1200mm |
| Cummins 4BTA3.9-C130 Construction Engine Specifications | |
| Engine Model | 4BTA3.9-C130 |
| Rated Power | 97kW/130HP |
| Rated Speed | 2200RPM |
| Engine Type | 4 Cylinders, in Line |
| Bore*Stroke(mm) | 102 mm * 120 mm |
| Displacement | 3.9 L |
| Compression Ratio | 18:01 |
| Peak Torque | 330N.m @1500r/min |
| Fuel Consumption | 18.6 L/hr |
| Aspiration Type | Turbocharged |
| Cooling Method | Water Cooled |
| Start Type | 24V, Electric Start |
| Fuel System | Wuxi Weifu A Pump/ RSV Govenor |
| Packing Weight | 500KG |
| Dimension | 1000mm*870mm*1200mm |
4089998 Lower Engine Gasket Set
Cummins 4089998 Lower Engine Gasket Set for ISM11/QSM11 engines
3638682 Exhaust Manifold
Cummins Exhaust Manifold 3633723 3638682 for Engine KTA38
4089848 Upper Engine Gasket Kit
4089848 Upper Engine Gasket Kit for Cummins K38/KTA38
KTA19-M3/KTA19-M640
Cummins KTA19-M3(640HP) Engine model from Chongqing Cummins Engine Company (CCEC).Genuine Cummins marine propulsion engine KTA19-M3 with sea water pump, heat exchanger, CCS/IMO certificates.if you need Cummins KTA19-M640 original/genuine engine spare parts catalog or manual,pls contact our sales team
