Cummins QSB4.5-C110 Engine Model from Dongfeng Cummins Engine Plant (DCEC Cummins). QSB4.5-C110 used for mining, construction and industrial efficient and economical engineering machinery engine,Cummins QSB4.5-C110 original/genuine engine spare parts catalog and manual.

Cummins QSB4.5-C110 Engineering Diesel Engine

Cummins  QSB4.5-C110 Construction Engine Specifications
Engine Model  QSB4.5-C110
Rated Power 82kW/110HP
Rated Speed 2700 RPM
Engine Type 4 Cylinders, in Line
Bore*Stroke(mm)  107mm * 124mm
Displacement  4.5 L
Compression Ratio  17.3: 1
Peak Torque 502N.m @1500r/min
Fuel Consumption 21.6 L/hr
Aspiration Type Turbocharged
Cooling Method Water Cooled
Start Type 24V, Electric Start
Fuel System HPCR
Packing Weight 368KG
Dimension 800mm*644mm*950mm
Cummins diesel engine  QSB4.5-C110 trade information
Warranty Time 1 year or 1000 hours, which one comes first
Delivery Port Shanghai or any China port
Leading Time 15 working days
Trade Termes FOB/CIF
Payement termes  T/T, L/C


(1) Cummins QSB4.5-C110 engine power pack with Radiator, Air Filter, Muffler, Engine Monitor, Engine Chassis avaialble
(2) We can provide the QSB4.5-C110 complete engine,also Cummins  QSB4.5-C110 genuine engine spare parts Cataloge.
