| Cummins ISMe308 Automotive Engine Specifications | |
| Engine Model | ISMe308 |
| Rated Power | 226kW/308HP |
| Rated Speed | 1900RPM |
| Engine Type | 6 Cylinders, Inline |
| Bore*Stroke(mm) | 125mm * 147mm |
| Displacement | 10.8 L |
| Compression Ratio | 16.2:1 |
| Peak Torque | 1450N.m @ 1200 rpm |
| Fuel Consumption | |
| Aspiration Type | Turbocharged |
| Cooling Method | Intercooled |
| Start Type | 24V, Electric Start |
| Fuel System | Direct Injection Pump |
| Packing Weight | 940 Kg |
| Dimension | 1335mm*825mm*1159mm |
| Cummins diesel engine ISMe308 trade information | |
| Warranty Time | 1 year or 1000 hours, which one comes first |
| Delivery Port | Shanghai or any China port |
| Leading Time | 15 working days |
| Trade Termes | FOB/CIF |
| Payement termes | T/T, L/C |
| Cummins ISMe335 Automotive Engine Specifications | |
| Engine Model | ISMe335 |
| Rated Power | 250kW/335HP |
| Rated Speed | 1900RPM |
| Engine Type | 6 Cylinders, Inline |
| Bore*Stroke(mm) | 125mm * 147mm |
| Displacement | 10.8 L |
| Compression Ratio | 16.2:1 |
| Peak Torque | 1410N.m @ 1200~1600 rpm |
| Fuel Consumption | |
| Aspiration Type | Turbocharged |
| Cooling Method | Intercooled |
| Start Type | 24V, Electric Start |
| Fuel System | Direct Injection Pump |
| Packing Weight | 940 Kg |
| Dimension | 1335mm*825mm*1159mm |
| Cummins ISMe340 Automotive Engine Specifications | |
| Engine Model | ISMe340 |
| Rated Power | 250kW/340HP |
| Rated Speed | 1900RPM |
| Engine Type | 6 Cylinders, Inline |
| Bore*Stroke(mm) | 125mm * 147mm |
| Displacement | 10.8 L |
| Compression Ratio | 16.2:1 |
| Peak Torque | 1669 N.m @ 1200 rpm |
| Fuel Consumption | |
| Aspiration Type | Turbocharged |
| Cooling Method | Intercooled |
| Start Type | 24V, Electric Start |
| Fuel System | Direct Injection Pump |
| Packing Weight | 940 Kg |
| Dimension | 1335mm*825mm*1159mm |
| Cummins ISMe345 Automotive Engine Specifications | |
| Engine Model | ISMe340 |
| Rated Power | 254kW/345HP |
| Rated Speed | 1900RPM |
| Engine Type | 6 Cylinders, Inline |
| Bore*Stroke(mm) | 125mm * 147mm |
| Displacement | 10.8 L |
| Compression Ratio | 16.2:1 |
| Peak Torque | 1710N.m @ 1200 rpm |
| Fuel Consumption | |
| Aspiration Type | Turbocharged |
| Cooling Method | Intercooled |
| Start Type | 24V, Electric Start |
| Fuel System | Direct Injection Pump |
| Packing Weight | 940 Kg |
| Dimension | 1335mm*825mm*1159mm |
| Cummins ISMe360 Automotive Engine Specifications | |
| Engine Model | ISMe340 |
| Rated Power | 254kW/345HP |
| Rated Speed | 1900RPM |
| Engine Type | 6 Cylinders, Inline |
| Bore*Stroke(mm) | 125mm * 147mm |
| Displacement | 10.8 L |
| Compression Ratio | 16.2:1 |
| Peak Torque | 1710N.m @ 1200 rpm |
| Fuel Consumption | |
| Aspiration Type | Turbocharged |
| Cooling Method | Intercooled |
| Start Type | 24V, Electric Start |
| Fuel System | Direct Injection Pump |
| Packing Weight | 940 Kg |
| Dimension | 1335mm*825mm*1159mm |
| Cummins ISMe380 Automotive Engine Specifications | |
| Engine Model | ISMe380 |
| Rated Power | 280kW/380HP |
| Rated Speed | 1900RPM |
| Engine Type | 6 Cylinders, Inline |
| Bore*Stroke(mm) | 125mm * 147mm |
| Displacement | 10.8 L |
| Compression Ratio | 16.2:1 |
| Peak Torque | 1825 N.m @ 1200 rpm |
| Fuel Consumption | |
| Aspiration Type | Turbocharged |
| Cooling Method | Intercooled |
| Start Type | 24V, Electric Start |
| Fuel System | Direct Injection Pump |
| Packing Weight | 940 Kg |
| Dimension | 1335mm*825mm*1159mm |
| Cummins ISMe385 Automotive Engine Specifications | |
| Engine Model | ISMe385 |
| Rated Power | 283kW/385H |
| Rated Speed | 1900RPM |
| Engine Type | 6 Cylinders, Inline |
| Bore*Stroke(mm) | 125mm * 147mm |
| Displacement | 10.8 L |
| Compression Ratio | 16.2:1 |
| Peak Torque | 1835N.m @ 1200 rpm |
| Fuel Consumption | |
| Aspiration Type | Turbocharged |
| Cooling Method | Intercooled |
| Start Type | 24V, Electric Start |
| Fuel System | Direct Injection Pump |
| Packing Weight | 940 Kg |
| Dimension | 1335mm*825mm*1159mm |
| Cummins ISMe420 Automotive Engine Specifications | |
| Engine Model | ISMe420 |
| Rated Power | 306kW/420HP |
| Rated Speed | 1900RPM |
| Engine Type | 6 Cylinders, Inline |
| Bore*Stroke(mm) | 125mm * 147mm |
| Displacement | 10.8 L |
| Compression Ratio | 16.2:1 |
| Peak Torque | 2010N.m @ 1200 rpm |
| Fuel Consumption | |
| Aspiration Type | Turbocharged |
| Cooling Method | Intercooled |
| Start Type | 24V, Electric Start |
| Fuel System | Direct Injection Pump |
| Packing Weight | 940 Kg |
| Dimension | 1335mm*825mm*1159mm |
| Cummins ISMe440 Automotive Engine Specifications | |
| Engine Model | ISMe440 |
| Rated Power | 324kW/440HP |
| Rated Speed | 1900RPM |
| Engine Type | 6 Cylinders, Inline |
| Bore*Stroke(mm) | 125mm * 147mm |
| Displacement | 10.8 L |
| Compression Ratio | 16.2:1 |
| Peak Torque | 2100 N.m @ 1200 rpm |
| Fuel Consumption | |
| Aspiration Type | Turbocharged |
| Cooling Method | Intercooled |
| Start Type | 24V, Electric Start |
| Fuel System | Direct Injection Pump |
| Packing Weight | 940 Kg |
| Dimension | 1335mm*825mm*1159mm |
| Cummins ISMe405 Automotive Engine Specifications | |
| Engine Model | ISMe405 |
| Rated Power | 298kW/405HP |
| Rated Speed | 1900RPM |
| Engine Type | 6 Cylinders, Inline |
| Bore*Stroke(mm) | 125mm * 147mm |
| Displacement | 10.8 L |
| Compression Ratio | 16.2:1 |
| Peak Torque | 2000 N.m @ 1200 rpm |
| Fuel Consumption | |
| Aspiration Type | Turbocharged |
| Cooling Method | Intercooled |
| Start Type | 24V, Electric Start |
| Fuel System | Direct Injection Pump |
| Packing Weight | 940 Kg |
| Dimension | 1335mm*825mm*1159mm |
| Cummins ISMe405 engine trade information | |
| Warranty Time | 1 year or 1000 hours, which one comes first |
| Delivery Port | Shanghai or any China port |
| Leading Time | 15 working days |
| Trade Termes | FOB/CIF |
| Payement termes | T/T, L/C |
Donaldson Air Fliter Safety
Remi Power Technology supply Genuine Donaldson Air Fliter Safety imported from USA, OEM quality and hight quality aftermarket as complementary options.
3906206 Valve Guide
3906206 Cummins intake and exhaust valve guide
3060905 Bushing
3060905 Bushing from Cummins G28, V28
3053476/3049438 Rocker Lever
Cummins K19 K38 K50 Lever, Rocker 3053476/3049438
