Cummins ISF3.8 Diesel Engine for Heavy truck

‹ ›

ISF3.8

Cummins Automotive Diesel Engine,Original from Dongfeng Cummins Engine Plant (DCEC). Cummins ISF3.8 widely use on Dongfeng Truck, Heavy truck, Bus, Van, Commercial vehicle Available for Cummins ISF3.8 genuine engine spare parts.

Product Model:

Enquiry

Cummins ISF3.8s3141

Cummins ISF3.8s3141 Automotive Engine Specifications
Engine Model	ISF3.8s3141
Rated Power	105kW/140HP
Rated Speed	2600RPM
Engine Type	4 Cylinders, Inline
Bore*Stroke(mm)	102mm * 115mm
Displacement	3.76 L
Compression Ratio	17.2:1
Peak Torque	450N.m @ 1200-2200rpm
Fuel Consumption	195 g/kW.h
Aspiration Type	Turbocharged
Cooling Method	Intercooled
Start Type	24V, Electric Start
Fuel System	Common Rail Direct Injection
Packing Weight	340Kg
Dimension	810mm695mm806mm
Cummins diesel engine ISF3.8s3141 trade information
Warranty Time	1 year or 1000 hours, which one comes first
Delivery Port	Shanghai or any China port
Leading Time	15 working days
Trade Termes	FOB/CIF
Payement termes	T/T, L/C

Cummins ISF3.8s3154

Cummins ISF3.8s3154 Automotive Engine Specifications
Engine Model	ISF3.8s3154
Rated Power	115kW/156HP
Rated Speed	2600RPM
Engine Type	4 Cylinders, Inline
Bore*Stroke(mm)	102mm * 115mm
Displacement	3.76 L
Compression Ratio	17.2:1
Peak Torque	500N.m @ 1200-1900rpm
Fuel Consumption	195 g/kW.h
Aspiration Type	Turbocharged
Cooling Method	Intercooled
Start Type	24V, Electric Start
Fuel System	Common Rail Direct Injection
Packing Weight	340Kg
Dimension	810mm695mm806mm

Cummins ISF3.8s3168

Cummins ISF3.8s3168 Automotive Engine Specifications
Engine Model	ISF3.8s3168
Rated Power	168KW (125HP)
Rated Speed	2600RPM
Engine Type	4 Cylinders, Inline
Bore*Stroke(mm)	102mm * 115mm
Displacement	3.76 L
Compression Ratio	17.2:1
Peak Torque	600N.m @ 1300-1700rpm
Fuel Consumption	195 g/kW.h
Aspiration Type	Turbocharged
Cooling Method	Intercooled
Start Type	24V, Electric Start
Fuel System	Common Rail Direct Injection
Packing Weight	340Kg
Dimension	810mm695mm806mm

Cummins ISF3.8s4141

Cummins ISF3.8s4141 Automotive Engine Specifications
Engine Model	ISF3.8s4141
Rated Power	105kW/140HP
Rated Speed	2600RPM
Engine Type	4 Cylinders, Inline
Bore*Stroke(mm)	102mm * 115mm
Displacement	3.76 L
Compression Ratio	17.2:1
Peak Torque	450N.m @ 1200-2200rpm
Fuel Consumption	195 g/kW.h
Aspiration Type	Turbocharged
Cooling Method	Intercooled
Start Type	24V, Electric Start
Fuel System	Common Rail Direct Injection
Packing Weight	340Kg
Dimension	810mm695mm806mm

Cummins ISF3.8s4154

Cummins ISF3.8s4154 Automotive Engine Specifications
Engine Model	ISF3.8s4154
Rated Power	115kW/154HP
Rated Speed	2600RPM
Engine Type	4 Cylinders, Inline
Bore*Stroke(mm)	102mm * 115mm
Displacement	3.76 L
Compression Ratio	17.2:1
Peak Torque	500N.m @ 1200-1900rpm
Fuel Consumption	195 g/kW.h
Aspiration Type	Turbocharged
Cooling Method	Intercooled
Start Type	24V, Electric Start
Fuel System	Common Rail Direct Injection
Packing Weight	340Kg
Dimension	810mm695mm806mm

Cummins ISF3.8s4168

Cummins ISF3.8s4168 Automotive Engine Specifications
Engine Model	ISF3.8s4168
Rated Power	125kW/168HP
Rated Speed	2600RPM
Engine Type	4 Cylinders, Inline
Bore*Stroke(mm)	102mm * 115mm
Displacement	3.76 L
Compression Ratio	17.2:1
Peak Torque	600N.m @ 1300-1700rpm
Fuel Consumption	195 g/kW.h
Aspiration Type	Turbocharged
Cooling Method	Intercooled
Start Type	24V, Electric Start
Fuel System	Common Rail Direct Injection
Packing Weight	340Kg
Dimension	810mm695mm806mm
Cummins diesel engine ISF3.8s4168 trade information
Warranty Time	1 year or 1000 hours, which one comes first
Delivery Port	Shanghai or any China port
Leading Time	15 working days
Trade Termes	FOB/CIF
Payement termes	T/T, L/C
