Cummmins EQB235-20 Engine Model from Dongfeng Cummins Engine Plant (DCEC Cummins). EQB235-20 Engine widely use on Dongfeng Truck, Heavy truck, Bus, Van, Commercial vehicle We can offer Cummins EQB235-20 genuine engine spare parts catalog and operation manual.

Cummins EQB235-20 Automotive Engine

Cummins EQB235-20 Automotive  Engine Specifications
Engine Model EQB235-20
Rated Power 173 kW/235HP
Rated Speed 2500 rpm
Engine Type 6 Cylinders in Line
Bore*Stroke(mm)  102*120mm
Displacement 5.9L
Compression Ratio 17.3:1
Peak Torque 800 N.m @ 1600 rpm
Fuel Consumption 242g/Kw.h
Aspiration Type Turbocharged
Cooling Method Intercooled
Start Type 24V, Electric Start
Fuel System  Wuxi Weifu Pump
Packing Weight 413 Kg
Dimension 1026mm*699mm*912mm
Cummins diesel engine EQB235-20 trade information
Warranty Time 1 year or 1000 hours, which one comes first
Delivery Port Shanghai or any China port
Leading Time 15 working days
Trade Termes FOB/CIF
Payement termes  T/T, L/C

(1) If you need the EQB235-20 engine power pack with the transmission, please further contact our sales.
(2) We can provide the EQB235-20 complete engine, as well as the EQB235-20 genuine Cummins engine spare parts.
