Genset Model | Prime Power | Engine Model | L/h | Cylinder | Displace | DiM | Weight | |
KVA | KW | L | mm | kg | ||||
DCEC Marine Generator | ||||||||
LM30CS-M | 37.5 | 30 | 4BTA3.9-GM47 | 8.5 | 4 | 3.9 | 1650x850x1270 | 650 |
LM40CS-M | 50 | 40 | 4BTA3.9-GM47 | 11 | 4 | 3.9 | 1650x850x1270 | 650 |
LM50CS-M | 62.5 | 50 | 6BT5.9-GM83 | 12.5 | 6 | 5.9 | 1980x895x1300 | 900 |
LM64CS-M | 80 | 64 | 6BT5.9-GM83 | 15.5 | 6 | 5.9 | 1980x895x1300 | 1000 |
LM75CS-M | 93.75 | 75 | 6BT5.9-GM83 | 18 | 6 | 5.9 | 1980x895x1300 | 1100 |
LM80CS-M | 100 | 80 | 6BTA5.9-GM100 | 19.2 | 6 | 5.9 | 1980x895x1300 | 1100 |
LM90CS-M | 112.5 | 90 | 6BTA5.9-GM100 | 21.8 | 6 | 5.9 | 2080x895x1300 | 1200 |
LM100CS-M | 125 | 100 | 6CT8.3-GM115 | 23 | 6 | 8.3 | 2140x810x1360 | 1500 |
LM120CS-M | 150 | 120 | 6CTA8.3-GM155 | 28.5 | 6 | 8.3 | 2180x810x1360 | 1600 |
LM150CS-M | 187.5 | 150 | 6LTAA8.9-GM200 | 35 | 6 | 8.3 | 2226x860x1670 | 1800 |
LM180CS-M | 225 | 180 | 6LTAA8.9-GM200 | 41.9 | 6 | 8.3 | 2289x860x1670 | 1850 |
CCEC Marine Generator with CCS & IMO II | ||||||||
LM200CS-M | 250 | 200 | N855-DM | 48.1 | 6 | 14 | 2760x1000x1780 | 3000 |
LM240CS-M | 300 | 240 | N855-DM | 57.8 | 6 | 14 | 2760x1000x1780 | 3200 |
LM280CS-M | 350 | 280 | N855-DM | 67.4 | 6 | 14 | 2990x1000x1780 | 3250 |
LM300CS-M | 375 | 300 | K19-DM | 72.2 | 6 | 19 | 3150x1000x1900 | 3700 |
LM350CS-M | 437.5 | 350 | K19-DM | 84.3 | 6 | 19 | 3150x1000x1900 | 3750 |
LM400CS-M | 500 | 400 | K19-DM | 96.3 | 6 | 19 | 3150x1000x1900 | 3800 |
LM500CS-M | 625 | 500 | K38-DM | 120.4 | 12 | 38 | 3950x1500x2500 | 6200 |
LM600CS-M | 750 | 600 | K38-DM | 144.5 | 12 | 38 | 4100x1500x2500 | 6350 |
LM630CS-M | 787.5 | 630 | K38-DM | 144.5 | 12 | 38 | 4100x1500x2500 | 6350 |
LM800CS-M | 1000 | 800 | K38-DM | 192.7 | 12 | 38 | 4100x1500x2500 | 7000 |
LM900CS-M | 1125 | 900 | QSK38-DM | 216.8 | 12 | 38 | 4250x1650x2500 | 7400 |
LM1000CS-M | 1250 | 1000 | K50-DM | 240.9 | 16 | 50 | 4300x1600x2600 | 8000 |
