Cummins KTA38-M2

‹ ›

KTA38-M2

Cummins KTA38-M2(1300HP) Engine model from Chongqing Cummins Engine Company (CCEC).Genuine Cummins marine propulsion engine KTA38-M2 with sea water pump, heat exchanger, CCS/IMO certificates.if you need Cummins KTA38-M1300 original/genuine engine spare parts catalog or manual,pls contact our sales team

Enquiry

Cummins KTA38-M2-1300 Marine Main Engine

Cummins KTA38-M2-1300HP Diesel Engine for Marine
Engine Model	KTA38-M1300
Rated Power	969kW/1300HP
Rated Speed	1800RPM
Engine Type	12 Cylinders, V Type
Bore*Stroke(mm)	159mm*159mm
Displacement	37.8 L
Compression Ratio	13.9:1
Peak Torque
Fuel Consumption	235 L/hr
Aspiration Type	Turbocharged & Aftercooled
Cooling Method	Water Cooled
Start Type	24V, Electric Start
Fuel System	Cummins PT Pump
Governor Method	Mechanical Governor
Packing Weight	4700KG
Dimension	2700mm1550mm2200mm
Cummins diesel engine KTA38-M2-1300HP trade information
Warranty Time	1 year or 1000 hours, which one comes first
Delivery Port	Shanghai or any China port
Leading Time	15 working days
Trade Termes	FOB/CIF
Payement termes	T/T, L/C
