Cummins QSK60 Genuine Spare Parts

All our QSK60/QSK60-M/QSK60-DM/QSK60-G genuine parts are imported from Cummins USA or Singapore.In this page you could find out the Cummins QSK60 engine's Main overhaul Parts, the usual parts numbers of the parts for Cylinder Block,Cylinder head,Fuel System, Lub Oil System, Turbocharger, Gasket kit. Or Be sure to give us Cummins engine series number, so that we can check the correct spare part number and correct price. In demanding mining applications such as excavators, haul trucks, and wheel loaders, dependability is everything. That’s where the superior uptime and productivity of the Tier 4 Final QSK60 make a difference. Its V16 configuration offers up to 2850 hp (2125 kW) in mining applications, with simplified air handling, reduced complexity, and improved serviceability.

Enquiry

Main Parts list for Cummins QSK60 engine

Item	P/N	Desctiption	qty
1	402797700	KIT,TUR REPAIR	4
2	353658800	SHIELD, TURBOCHARGER	2
3	367878600	SEAL O RING	16
4	359153200	BEARING,TUR THRUST	2
5	352398000	SLINGER,OIL	2
6	408842800	INJECTOR ICI	16
7	364451800	PUMP,LUBRICATING OIL	1
8	408920100	SET, QUARANT AFT CLR GSK	4
9	402479200	SET MAIN BEARING (STD)	1
10	308231500	GASKET, EXHAUST MANIFOLD	12
11	406556600	THERMOSTAT	2
12	362920500	THERMOSTAT	4
13	4382800	CLAMP;HOSE 2.56-3.5 RANGE	2
14	307565800	SEAL O RING	2
15	400790100	HOSE,PLAIN	1
16	308901900	SEAL,O RING	1
17	317903500	GASKET;WTR TRF CONNECTION	1
18	304081700	SEAL O RING	3
19	308570900	SEAL, O RING	1
20	308623400	SEAL O RING	1
21	333229100	GASKET;ROCKER COVER	16
22	410066000	SEAL O RING	16
23	333229800	GASKET,HYDRAULIC PUMP	1
24	16983400	CLIP	1
25	333216000	SEAL, O RING	2
26	390266200	NUT;HEXAGON FLANGE	4
27	390246000	SCREW;HEX FLANGE HEAD CAP	6
28	AS0402000SL	HOSE,FLEXIBLE	1
29	406613500	GASKET, FILTER HEAD	1
30	406613600	GASKET, FILTER HEAD	1
31	363332500	SEAL,O RING	2
32	406682700	GASKET, THERMOSTAT HOUSING	3
33	390063300	SCREW;HEX FLANGE HEAD CAP	2
34	390063000	SCREW;HEX FLANGE HEAD CAP	2
35	308989100	SEAL RECTANGULAR RING	1
36	S00096200E	DRAINCOCK	2
37	409782100	SEAL,FERRULE	2
38	308931800	GASKET,FLANGE	1
39	308931900	GASKET,FLANGE	1
40	410115000	GASKET, CONNECTION	3
41	308995500	GASKET,CONNECTION	4
42	367860600	SEAL,O RING	12
43	362769500	SEAL;O-RING	10
44	363605900	NUT,HEXAGON FLANGE	16
45	308932100	SPACER, MOUNTING	16
46	400083700	SCREW, HEX FLANGE HEAD CAP	16
47	406561500	GASKET,TURBOCHARGER	4
48	S00050500	PIN,COTTER	4
49	491613800	PIN,CLEVIS	4
50	287072000	LATCH,SIDE PANEL	4
51	308901600	CAPSCREW;HEX FLANGE	2
52	390399000	SCREW;HEX FLANGE HEAD CAP	6
53	333218300	GASKET, CONNECTION	1
54	390063500	SCREW, HEX FLANGE HEAD CAP	7
55	364955100	SEAL,OIL	1
56	402617100	GASKET;FUEL PUMP	1
57	304620000	SPIDER;JAW COUPLING	1
58	400175600	VALVE,PRESSURE REGULATOR	1
59	334858300	GASKET,PRS RLF VALVE BODY	1
60	304254200	SEAL;O RING	1
61	386539800	SEAL O RING	1
62	386739300	SCREEN FILTER	1
63	309076900	SCREEN;FILTER	1
64	304694300	SEAL;O RING	1
65	332858900	SEAL,O RING	2
66	401051900	SEAL O RING	1
67	306691400	SEAL;O RING	1
68	306691400	SEAL;O RING	1
69	333216000	SEAL, O RING	2
70	364396100	SHAFT,WATER PUMP	2
71	300751200	SEAL,O RING	3
72	363400700	SEAL, WATER PUMP	3
73	364396000	SEAL,OIL	3
74	S01605400	BEARING;BALL	2
75	S01606900	BEARING;BALL	2
76	363175700	PIN,GUIDE	1
77	363176000	PIN,STRAIGHT	2
78	339358300	WASHER,PLAIN	1
79	339358200	WASHER,PLAIN	1
80	339358100	WASHER,PLAIN	2
81	363175900	PIN,COTTER	2
82	339359200	PAPER	1
83	406578500	O-RING	4
84	364398400	BEARING,CON ROD (STD)	32
85	400722600	SCREW	64
86	364942100	SHAFT,CENTRIFUGE	1
