KTA19-C

Cummins KTA19-C Engineering diesel engine,Original from Chongqing Cummins Engine Plant (CCEC). Cummins KTA19-C450,KTA19-C525,KTA19-C525,KTA19-C600,KTTA19-C700,KTA19-P450,KTA19-P500,KTA19-P600,KTA19-P680,KTA19-P700,KTA19-P750,QSK19-C600,QSKTAA19-C700,QSKTAA19-C755 widely use on Heavy truck, Excavator, Road roller, Bulldozer, Crane, water pump Available for Cummins KTA19-C genuine engine spare parts.
Enquiry

Cummins KTA19-C450



Cummins KTA19-C450 Construction Engine Specifications
Engine Model KTA19-C450
Rated Power 336 kW/450HP
Rated Speed 2100RPM
Engine Type 6 Cylinders, Inline
Bore*Stroke(mm)  159mm*159mm
Displacement  19 L
Compression Ratio  13.9 : 1
Peak Torque  1830 N.m @ 1500 rpm
Fuel Consumption 210g/Kw.h
Aspiration Type Turbocharged
Cooling Method Intercooled
Start Type 24V, Electric Start
Fuel System  Cummins PT Pump
Packing Weight  2073Kg
Dimension 2151mm*966mm*1704mm
Cummins diesel engine KTA19-C450 trade information
Warranty Time 1 year or 1000 hours, which one comes first
Delivery Port Shanghai or any China port
Leading Time 15 working days
Trade Termes FOB/CIF
Payement termes  T/T, L/C





Cummins KTA19-C525

Cummins KTA19-C525 Construction Engine Specifications
Engine Model KTA19-C525
Rated Power  373 kW/525 HP
Rated Speed 2100RPM
Engine Type 6 Cylinders, Inline
Bore*Stroke(mm)  159mm*159mm
Displacement  19 L
Compression Ratio  13.9 : 1
Peak Torque  1870 N.m @ 1500 rpm
Fuel Consumption 210g/Kw.h
Aspiration Type Turbocharged
Cooling Method Intercooled
Start Type 24V, Electric Start
Fuel System  Cummins PT Pump
Packing Weight  2073Kg
Dimension 2151mm*966mm*1704mm





Cummins KTA19-C525



Cummins KTA19-C525 Construction Engine Specifications
Engine Model KTA19-C525
Rated Power  373 kW/525 HP
Rated Speed 2100RPM
Engine Type 6 Cylinders, Inline
Bore*Stroke(mm)  159mm*159mm
Displacement  19 L
Compression Ratio  13.9 : 1
Peak Torque  1870 N.m @ 1500 rpm
Fuel Consumption 210g/Kw.h
Aspiration Type Turbocharged
Cooling Method Intercooled
Start Type 24V, Electric Start
Fuel System  Cummins PT Pump
Packing Weight  2073Kg
Dimension 2151mm*966mm*1704mm





Cummins KTA19-C600

Cummins KTA19-C600 Construction Engine Specifications
Engine Model KTA19-C600
Rated Power  448 kW/600 HP
Rated Speed 2100RPM
Engine Type 6 Cylinders, Inline
Bore*Stroke(mm)  159mm*159mm
Displacement  19 L
Compression Ratio  13.9 : 1
Peak Torque  2237 N.m @ 1500 rpm
Fuel Consumption 210g/Kw.h
Aspiration Type Turbocharged
Cooling Method Intercooled
Start Type 24V, Electric Start
Fuel System  Cummins PT Pump
Packing Weight  2073Kg
Dimension 2151mm*966mm*1704mm



Cummins KTTA19-C700

Cummins KTTA19-C700 Construction Engine Specifications
Engine Model KTTA19-C700
Rated Power 522 kW/700 HP
Rated Speed 2100RPM
Engine Type 6 Cylinders, Inline
Bore*Stroke(mm)  159mm*159mm
Displacement  19 L
Compression Ratio  13.9 : 1
Peak Torque  2730 N.m @ 1400 rpm
Fuel Consumption 210g/Kw.h
Aspiration Type Turbocharged
Cooling Method Intercooled
Start Type 24V, Electric Start
Fuel System  Cummins PT Pump
Packing Weight  2073Kg
Dimension 2151mm*966mm*1704mm





Cummins KTA19-P450

Cummins KTA19-P450 Construction Engine Specifications
Engine Model KTA19-P450
Rated Power 336 kW/450HP
Rated Speed 2100RPM
Engine Type 6 Cylinders, Inline
Bore*Stroke(mm)  159mm*159mm
Displacement  19 L
Compression Ratio  13.9 : 1
Peak Torque 1907 N.m @ 1300 rpm
Fuel Consumption 210g/Kw.h
Aspiration Type Turbocharged
Cooling Method Intercooled
Start Type 24V, Electric Start
Fuel System  Cummins PT Pump
Packing Weight  2073Kg
Dimension 2151mm*966mm*1704mm





Cummins KTA19-P500



Cummins KTA19-P500 Construction Engine Specifications
Engine Model KTA19-P500
Rated Power 373 kW/500 HP
Rated Speed 1500/1800 rpm
Engine Type 6 Cylinders, Inline
Bore*Stroke(mm)  159mm*159mm
Displacement  19 L
Compression Ratio  13.9 : 1
Peak Torque  1978 N.m @ 1575 rpm
Fuel Consumption 210g/Kw.h
Aspiration Type Turbocharged
Cooling Method Intercooled
Start Type 24V, Electric Start
Fuel System  Cummins PT Pump
Packing Weight  2073Kg
Dimension 2151mm*966mm*1704mm





Cummins KTA19-P600

Cummins KTA19-P600 Construction Engine Specifications
Engine Model KTA19-P600
Rated Power  448 kW/600 HP
Rated Speed 1500/1800 rpm
Engine Type 6 Cylinders, Inline
Bore*Stroke(mm)  159mm*159mm
Displacement  19 L
Compression Ratio  13.9 : 1
Peak Torque  2374 N.m @ 1751 rpm
Fuel Consumption 210g/Kw.h
Aspiration Type Turbocharged
Cooling Method Intercooled
Start Type 24V, Electric Start
Fuel System  Cummins PT Pump
Packing Weight  2073Kg
Dimension 2151mm*966mm*1704mm





Cummins KTA19-P680

Cummins KTA19-P680 Construction Engine Specifications
Engine Model KTA19-P680
Rated Power  507 kW/680 HP
Rated Speed 1500 rpm
Engine Type 6 Cylinders, Inline
Bore*Stroke(mm)  159mm*159mm
Displacement  19 L
Compression Ratio  13.9 : 1
Peak Torque 3237 N.m @ 2387 rpm
Fuel Consumption 210g/Kw.h
Aspiration Type Turbocharged
Cooling Method Intercooled
Start Type 24V, Electric Start
Fuel System  Cummins PT Pump
Packing Weight  2073Kg
Dimension 2151mm*966mm*1704mm



Cummins KTA19-P700

Cummins KTA19-P700 Construction Engine Specifications
Engine Model KTA19-P700
Rated Power  522 kW/700 HP
Rated Speed 1500 rpm
Engine Type 6 Cylinders, Inline
Bore*Stroke(mm)  159mm*159mm
Displacement  19 L
Compression Ratio  13.9 : 1
Peak Torque  2769 N.m @ 2042 rpm
Fuel Consumption 210g/Kw.h
Aspiration Type Turbocharged
Cooling Method Intercooled
Start Type 24V, Electric Start
Fuel System  Cummins PT Pump
Packing Weight  2073Kg
Dimension 2151mm*966mm*1704mm





Cummins KTA19-P750

Cummins KTA19-P750 Construction Engine Specifications
Engine Model KTA19-P750
Rated Power 559 kW/750 H
Rated Speed 1500 rpm
Engine Type 6 Cylinders, Inline
Bore*Stroke(mm)  159mm*159mm
Displacement  19 L
Compression Ratio  13.9 : 1
Peak Torque  2967 N.m @ 2188 rpm
Fuel Consumption 210g/Kw.h
Aspiration Type Turbocharged
Cooling Method Intercooled
Start Type 24V, Electric Start
Fuel System  Cummins PT Pump
Packing Weight  2073Kg
Dimension 2151mm*966mm*1704mm
