QSK23-C

Cummins QSK23 diesel engine is a diesel engine manufactured by Dongfeng Cummins. Its rated speed is 1500 rpm. The fuel specification and grade are national standard 0 diesel. The 12-hour power is 650KW and the 1-hour power is 720KW. In addition, the lubricating oil specifications and grades of this diesel engine are CD15W/40 and above, the oil consumption rate is ≤1g/, the fuel consumption rate is ≤205g/, the maximum lubricating oil temperature is 98°C, the bore x stroke is 130x163, and the number of cylinders is 6 cylinders In-line, the displacement is 23.
Enquiry
Model Rated power@speed Max.torque@speed Application
Cummins QSK23 1050hp/783kw@2100rpm 3928N.m@1400rpm
Cummins QSK23 1000hp/746kw@1800rpm 4128N.m@1600rpm
Cummins QSK23 950hp/708kw@2100rpm 3928N.m@1400rpm
Cummins QSK23 950hp/708kw@1800rpm 3776N.m@1400rpm
Cummins QSK23 860hp/641kw@2100rpm 3776N.m@1400rpm
Cummins QSK23 860hp/641kw@1800rpm 3776N.m@1400rpm with modification as Komatsu SAA6D170E-5 for Komatsu PC1250-8
Cummins QSK23 760hp/567kw@2100rpm 3468N.m@1350rpm
Cummins QSK23 760hp/567kw@1800rpm 3468N.m@1350rpm Hitachi EX1200-7
