Weichai X6170ZC Engine Parts Catalog

In this page you could find out the Weichai X6170ZC engine Parts,All our X6170ZC genuine parts , the usual parts numbers of the parts for Cylinder Block,Cylinder head,Fuel System, Lub Oil System, Turbocharger, Gasket kit. Or Be sure to give us Cummins engine series number, so that we can check the correct spare part number and correct price. In demanding mining applications such as excavators, haul trucks, and wheel loaders, dependability is everything.
Enquiry

Weichai X6170ZC  Engine Parts Catalog

ITEMS  DESCRIPCION  PARTE # QTY
1 CYLINDER HEAD COMPLETE 170Z.03.20.01 3
2 CLAMPING PLATE 170Z.03.32 2
3 EXHAUST VALVE 170Z.03.22A 18
4 WATER JACKET 170Z.03.25 6
5 INTAKE VALVE 170Z.03.05A 16
6 CLAMPING CAP 170Z.03.20.07A 6
7 SLEEVE 170Z.03.20.06 4
8 EXHAUST VALVE INSERT 170Z.03.20.03 18
9 INTAKE VALVE INSERT 170Z.03.20.12 18
10 RUBBER WASHER  170Z.03.20.12 12
11 VALVE GUIDE  170Z.03.20.05 24
12 GASKET 170Z.03.08 12
13 SPLIT VALVE LOCK 61500050025 48
14 SPRING SEAT 170Z.03.09A 24
15 OUTER VALVE SPRING 170Z.03.41 24
16 INNER VALVE SPRING 170Z.03.42 24
17 PLUG SCREW 170Z.01.35 2
18 SPRING 170Z.01.34 2
19 VALVE 170Z.01.33 2
20 TURNING CONNECTION BOLT 170Z.01.31 2
21 SPRAYING NOZZLE SUB-ASSY 170Z.01.20 6
22 WASHER  170.01.57 6
23 CYLINDER 617001180004 6
24 BRACKET 170Z.01.66 1
25 WATER PROOF RING 170Z.01.85 6
26 UPPER SHELL PIN 170Z.01.38 7
27 LOWER SHELL PIN 170Z.01.37 7
28 DOUBLE LANDDERRING 170Z.05.02 6
29 RECTANGULAR RING 170Z.05.12 6
30 CONICAL RING 170Z.05.03 6
31 SPIRAL SPRING OIL RING 170Z.05.10 6
32 PISTON 170Z.05.01A 3
33 PISTON PIN 170Z.05.04 3
34 CONNECTING ROD ASSEMBLY 170Z.05.20 3
35 BEARING 170Z.05.07 6
36 PLUG  617009000011 2
37 PLUG 617009000012 2
38 ROTATING SPEED SENSOR 170Z.09.52 2
39 OIL TEMPERATUER SENSOR 170Z.09.48 2
40 WATER TEMPERATURE SENSOR 170Z.09.47 2
41 FUEL PRESSURE SENSOR 170Z.09.45 2
42 ELECTRONIC ROTATING SPEED GAUDE WIRE 170Z.09.48 2
43 PARKING ELECTROMAGNETIC VALVE WIRE 170Z.09.51 2
44 HAND OIL PUMP ASSEMBLY 170Z.11.00 1
